Kaifeng XinYa Instrument Co., Ltd.
Global Provider of Industrial Flow Measurement & IoT Solutions
Contact Information:
- Email: xinya@sytcflowmeter.com
- WhatsApp: +86 15137867592
- Fax: +86 371-23668496
- Address: No.1, Ba Qing Wu Road, Jinming Avenue, South Section, Kaifeng Demonstration Area, Henan, China
Navigation: Home | Solutions | Industries | Products | IoT Platform | Resources | Contact
Flow Measurement Solutions by Category
Electromagnetic Flowmeter Product Lines
Standard Industrial Electromagnetic Flowmeters
- SF-E Electromagnetic Flowmeter Series
- Accuracy ratings: ±0.5%, ±0.3%, ±0.2%
- Pipe diameter range: DN15 to DN3000
- Velocity measurement: 0.1 to 10 m/s
- Signal outputs: 4-20mA, frequency, pulse
- Configuration: Integral or Split Type deployment
- Protection: IP65/IP66/IP67 (converter), IP68 (sensor)
Slurry & Abrasive Media Electromagnetic Flowmeters
- Slurry Electromagnetic Flowmeter (Specialized for High Solid Content)
- Target Applications: Coal-water slurry, mineral tailings, pulp, mining slurries
- Wear-Resistant Design: Polyurethane, PFA, and ceramic lining options (DN15-150)
- Solid Particle Handling: Variation restraint arithmetic for cuspidal disturb suppression
- Signal Stability Technology: Advanced filtering for solid grain friction interference
- Grounding System: Integrated 1-2 grounding electrodes for non-conductive pipes
- Chemical Resistance: Multiple rubber lining options for corrosive environments
- Mining Industry Optimization: Extended service life in high-abrasion conditions
Remote & Battery-Powered Flow Measurement
- Battery-Powered Wireless Flowmeter
- Power-independent operation for remote locations
- IP68 submersible rating (up to 3 meters water depth)
- 120-month internal data retention
- GPRS/RS485 wireless connectivity
- Heat measurement functionality (enthalpy-based calculations)
- Automatic sleep mode for battery conservation
Large Diameter Insertion Flowmeters
- SF-C Insertion Electromagnetic Flowmeter
- Cost-effective solution for DN3000 pipelines
- Ball valve mounting for hot-tap installation
- Adjustable insertion depth (half or quarter diameter)
- Stainless steel construction for structural integrity
- Municipal water and industrial process applications
Hygienic & Sanitary Flow Measurement
- SF-W Food Safety Electromagnetic Flowmeter
- Food, beverage, and pharmaceutical compliance
- Sanitary design preventing bacterial growth
- Materials compliant with food safety standards
- Second edition documentation (August 2023 release)
Industry Applications & Vertical Markets
Mining & Mineral Processing
- Tailings slurry measurement
- Mineral concentrate flow monitoring
- Coal-water slurry applications
- Abrasive media handling with wear-resistant technology
- Solid particle suspension measurement
Metals & Heavy Industry
- Ferrous and non-ferrous metal processing
- Blast furnace slurry systems
- Metallurgical process fluids
- High-temperature corrosive media
Energy & Power Generation
- Cooling water flow measurement
- Heat measurement for thermal systems (CJ128-2007 compliant)
- Wind and solar farm monitoring
- Power plant auxiliary systems
Oil, Gas & Petrochemical
- Refining facility process measurement
- Crude oil and refined product metering
- Chemical process control
- Corrosive fluid handling
Municipal Water & Wastewater
- Water distribution networks
- Wastewater treatment flow monitoring
- Remote water resource management
- Submerged sensor installations
Food & Beverage
- Hygienic fluid processing
- Ingredient flow control
- CIP (Clean-in-Place) system monitoring
- Pharmaceutical water systems
Manufacturing & Industrial Processing
- Automotive production lines (welding fluids)
- Electronics manufacturing (PCB/semiconductor processing)
- Machinery and equipment OEM applications
- General industrial fluid management
Technology Platform & IoT Capabilities
Instrument IoT Big Data Platform
- Platform Address: 124.95.128.250 (Web-based management)
- Real-Time Monitoring: 5-second default data refresh rate
- Historical Analytics: 60-point trend curve tracking
- Data Visualization: Cloud-based dashboard for multi-node monitoring
- Communication Protocols: RS485, RS232, HART, GPRS, Bluetooth, WiFi (STA/AP)
- API Integration: RESTful HTTP GET/POST with JSON data format
- MODBUS-RTU: International standard protocol compliance
- Security: 6-level password protection system
Advanced Signal Processing Technology
- Square Wave Pulse Excitation: Zero-point stability optimization
- VFC (Voltage-to-Frequency Conversion): High-input-impedance amplification
- Bidirectional Constant Current Drive: Variable frequency excitation systems
- Energy Recovery: Novel power-saving technology in magnetic field reversal
- SMT Circuit Design: Surface Mount Technology for reliability
Technical Standards & Certifications
Industry Standard Compliance
- JB/T 9248-2015: Electromagnetic Flowmeter National Standard
- GB/T 9124.1-2019: Steel Pipe Flanges Standard
- CJ128-2007: Heat Measurement Calculation Standard
- MODBUS-RTU: International Communication Protocol
Protection & Safety Ratings
- IP68: Sensor units (submersible, dust-tight)
- IP65/IP66/IP67: Converter units (dust-tight, water-resistant)
Product Selection by Application Scenario
For Abrasive & Slurry Applications (Mining, Tailings, Pulp)
→ Slurry Electromagnetic Flowmeter
- Wear-resistant lining materials
- Solid particle interference suppression
- Grounding electrode system
For Remote or Power-Limited Locations
→ Battery-Powered Wireless Flowmeter
- Long-term battery operation
- IP68 submersible capability
- GPRS remote data transmission
For Very Large Pipelines (DN1000-DN3000)
→ SF-C Insertion Electromagnetic Flowmeter
- Cost-effective installation
- Hot-tap mounting capability
For Food, Beverage, Pharmaceutical Industries
→ SF-W Food Safety Electromagnetic Flowmeter
- Hygienic material construction
- Sanitary design standards
For Standard Industrial Processes
→ SF-E Electromagnetic Flowmeter
- High accuracy (±0.2% option)
- Multiple signal outputs
- Wide diameter range (DN15-DN3000)
Core Measurement Capabilities
Measurement Performance
- Accuracy Options: ±0.5%, ±0.3%, ±0.2%
- Velocity Range: 0.1 to 10 m/s
- Pipe Diameter Range: DN15 to DN3000
- Bidirectional Flow: Automatic forward/reverse measurement
- Data Accumulation: 120 months internal storage
Self-Diagnostic Functions
- Empty pipe detection
- Excitation circuit break alarm
- Flow range overflow detection
- Automatic troubleshooting guidance
Output Signal Options
- 4-20mA analog output
- Frequency output
- Pulse output
- Digital communication (RS485/RS232/HART/MODBUS)
Engineering & Deployment Services
Customization Options
- Flange standard selection (GB/T 9124.1-2019 compliant)
- Electrode material selection (platinum, tantalum, stainless steel, others)
- Lining material customization (rubber, PTFE, PFA, polyurethane, ceramic)
- Communication module configuration
Installation Support
- Pre-installation inspection guidance
- Hot-tap installation for insertion meters
- Grounding system design for non-conductive pipes
- 10-minute preheating procedure documentation
After-Sales & Maintenance
- Remote troubleshooting via IoT platform
- Factory-calibrated replacement circuit boards
- Zero accuracy loss component replacement
- Technical training for maintenance teams
Development Milestones & Product Evolution
- August 2023: SF-W Food Safety Flowmeter (2nd Edition) manual release
- August 2024: SF-E Electromagnetic Flowmeter and Battery-Powered series (1st Edition) documentation
- April 2026: Advanced Slurry Electromagnetic Flowmeter documentation (scheduled)
Case Study Highlights
Industrial IoT Integration
Enabled real-time multi-node flow monitoring with 5-second refresh rates and 60-point historical tracking, improving operational transparency across facility networks.
Slurry Management in Mining
Deployed wear-resistant meters with spike suppression algorithms for coal-water slurry applications, maintaining signal stability despite high solid-grain friction.
Remote Water Resource Monitoring
Installed battery-powered IP68 units in submerged environments with 120-month data retention and GPRS connectivity for municipal water management.
Request Technical Consultation
For Application-Specific Guidance:
- Slurry flow measurement in mining operations
- Electromagnetic flowmeter selection for abrasive media
- IoT platform integration for multi-site monitoring
- Custom engineering for special materials or conditions
Contact Our Technical Team:
- Email: xinya@sytcflowmeter.com
- WhatsApp: +86 15137867592
Quick Links & Resources
- IoT Platform Access – Web-based device management
- Product Documentation – Technical manuals and specifications
- Industry Application Guides – Sector-specific solution briefs
- Installation Videos – Step-by-step deployment tutorials
- Technical Support Portal – Troubleshooting and FAQs
Company Information
Kaifeng XinYa Instrument Co., Ltd. specializes in high-stability electromagnetic flow measurement systems integrated with IoT big data platforms. Our solutions address critical industrial challenges including signal stability in abrasive environments, power consumption in remote areas, and cloud-based data integration for operational optimization.
Global Reach: Serving industrial, municipal, and food safety applications worldwide with high-precision fluid measurement and IoT monitoring solutions.
Core Technology: Square wave pulse excitation and VFC technology ensuring zero-point stability across diverse conductive media, combined with proprietary variation restraint algorithms for solid particle interference suppression.
